Stacking Mount Head
Stacking TV Ceiling Mount Head for 32 to 86 Inch
SKU 33CE018HEAD · MPN 33CE018HEAD
The 33CE018HEAD is a stacking ceiling mount head for the 33CE018 double-stack system, rated to 176 lb and fitting VESA patterns up to 600 x 400 mm. It tilts 10 degrees down and 5 degrees up and rotates 360 degrees.
Specifications
| Weight capacity | 176 lb |
|---|---|
| Tilt | 10° down |
| Rotation | 360° |
| VESA mounting range | 50 × 75 mm to 700 × 400 mm |
| Mast / pipe system | 1.5 in NPT |
| Manufacturer | Expert AV Products, Inc. |
| Fits VESA standards (mm) | 100x100, 100x200, 100x300, 100x400, 200x100, 200x200, 200x300, 200x400, 300x100, 300x200, 300x300, 300x400, 400x100, 400x200, 400x300, 400x400, 500x100, 500x200, 500x300, 500x400, 600x100, 600x200, 600x300, 600x400 |
Details
This head threads onto the 1.5" NPT mast of the double-stack mount, where two heads share one pipe below a ceiling plate. It adds or replaces a screen position on that mast. The mounting plate accepts VESA rails from 50 x 75 mm up to 700 x 400 mm, and each head carries its own display independently of the other.
The head tilts 10 degrees down and 5 degrees up and rotates a full 360 degrees, so a stacked screen can be aimed apart from the one above or below it. Confirm the display falls within the supported VESA range and weighs no more than 176 lb. Never exceed the rated capacity, and because the assembly is suspended overhead, professional installation is recommended for ceiling products.
