Mount Head
TV Ceiling Mount Head for 32 to 86 Inch, Tilt and Rotate
SKU 33CE008HEAD · MPN 33CE008HEAD
The 33CE008HEAD is a ceiling mount head that threads onto a 1.5" NPT mast, sized for flat panels from 32 to 86 inches and rated to 176 lb on the 33CE008 mount. It tilts 10 degrees down and 5 degrees up, rotates 360 degrees, and fits VESA patterns up to 600 x 400 mm.
Specifications
| Recommended screen size | 32 to 86 in |
|---|---|
| Weight capacity | 176 lb |
| Tilt | 10° down |
| Rotation | 360° |
| VESA mounting range | 50 × 75 mm to 700 × 400 mm |
| Mast / pipe system | 1.5 in NPT |
| Manufacturer | Expert AV Products, Inc. |
| Fits VESA standards (mm) | 100x100, 100x200, 100x300, 100x400, 200x100, 200x200, 200x300, 200x400, 300x100, 300x200, 300x300, 300x400, 400x100, 400x200, 400x300, 400x400, 500x100, 500x200, 500x300, 500x400, 600x100, 600x200, 600x300, 600x400 |
Details
This head is the screen end of the Expert Mounts ceiling-mount system. It threads onto 1.5" NPT pipe - a fixed length or a telescoping extension - suspended below a ceiling plate matched to the building structure. Because the pipe sets the drop distance, the head stays the same whether the screen hangs close to the ceiling or well below it. Its mounting plate accepts VESA rails from 50 x 75 mm up to 700 x 400 mm.
The head tilts 10 degrees down and 5 degrees up to angle the screen toward viewers, and rotates a full 360 degrees. To select it, confirm the display measures between 32 and 86 inches diagonally, that its VESA pattern falls within the supported range, and that its weight is at or below the 176 lb rating. Never exceed the rated capacity, and because the load is carried overhead, professional installation is recommended for ceiling products.
