Fixed Wall Mount
Fixed TV Wall Mount for 15 to 37 inch
SKU 22FW002 · MPN 22FW002
Fixed wall mount for flat panels from 15 to 37 inches, rated to 100 lb. The screen sits 0.75" from the wall. Fits VESA mounting patterns from 75 x 75 to 200 x 200 mm. Silver finish; a complete hardware kit is included.
Specifications
| Recommended screen size | 15 to 37 in |
|---|---|
| Weight capacity | 100 lb |
| Tilt | None (fixed) |
| VESA mounting range | 75 × 75 mm to 200 × 200 mm |
| Profile (distance from wall) | 0.75 in |
| Manufacturer | Expert AV Products, Inc. |
| Fits VESA standards (mm) | 75x75, 100x100, 200x100, 200x200 |
Details
This mount uses slide-together mounting plates. One piece fastens to the wall, the other bolts to the rear VESA holes on the display, and the display slides down onto the wall plate to seat. The same motion works in reverse, so the screen lifts off for cable access or can be exchanged for another display on the same wall plate. Check that the display's hole pattern falls within 75 x 75 to 200 x 200 mm. The wall plate must anchor to wall structure, studs or masonry, not to drywall alone.
A fixed mount has no moving parts, so there is nothing to adjust or work loose over time; the screen hangs flat at whatever height it is installed. Set that height at eye level for the intended viewers, because the angle is not adjustable afterward. Typical uses include monitors and mid-size displays in offices, waiting rooms, restaurants, and digital signage. Do not exceed the 100 lb rating.
